Action essentials free download mac. 2.2.2 Two ways of adding camera (1)Adding by inputting IP address(For getting camera ip address, please refer to search tool or lan search) (2)Search under LAN 1) Adding by inputting IP address Step 1: Click button to bring up the Add Device dialog box. Step 2: Fill in the camera IP in the 'IP or Domain name' field, other port remain default(80).

1. Network P2p Wifi Ip Cameras User Manual Pdf
2. Network P2p Wifi Ip Cameras User Manuals

• P2P Wireless IP camera User Manual PC client version 2.1 Brief Instruction: Real Plug and Play(P2P) is brand new technology for ip camera market. The ip cameras could be more easy to install and use. With the p2p ip camera: 1.No need to set up port forward 2.No need to apply additional DDNS 3.No need to change router’s configuration.
• Manual Setup for WiFi Cameras with WiFi Router: Simple steps to connect camera to WiFi network via PC or Mac: 1. Connect camera to power using 12V DC power adapter and wait approx. 30 seconds for camera to initialize. NOTE: PoE can also be used to power camera. Connect camera to WiFi router using Ethernet Cable. Download and install IP.
• This is an integrated wireless IP Camera solution. It combines a high quality digital Video Camera with network connectivity and a powerful web server to bring clear pictures to your Desktop from anywhere on your local network or over the Internet. The main function of the camera is to transmit remote video over IP network.
• 1) Turn on camera: Press “ON/OFF ” to turn on the camera, in 10 seconds, and the blue light bright, the red light flashes slowly. 2) Go to the WIFI setting page, then connect the Wi-Fi named “ IPC-XXXXX ”. 3) Open 'HIDVCAM', Refresh the device list on the APP, you can view connected camera.
• FOSCAM Indoor HD IP Camera is an integrated wireless IP Camera with a color CMOS sensor which enable to view in High Definition resolution. It combines a high quality digital video camera, with a powerful web server, to bring clear video to your desktop and mobile devices no matter where by your local network or over the Internet.
• IPCAM User Manual 4.2 Setting Wi-Fi of IP Camera 1) To use the wireless functions of the IP Camera,a wireless router like linksys is required. 2) Enter the wireless router setup page(you may see the wireless router user manual).To Find out the SSID, Channel(less than 10), Security Way(NONE,WEP),Authentication Type,encryption.

This IP Camera can send high-quality live video with sound through the Internet to a web browser anywhere in the world. Both wired and wireless network connections are available. Once you choose it, you will be amazed at its abundant features and richer functionality. From now on, you can record what happened in your life faithfully, vividly and permanently.
Features:
* H.264 1/4' Color CMOS Sensor 1,000k Pixels.
* Support QR Code Scanning.
* Maximum support 32GTF Card.
* High image & video quality, Two-way audio monitoring.
* Both wired and wireless network connections are available.

Network P2p Wifi Ip Cameras User Manual Pdf

* P2P(Plug & Play)technology, penetration degree can be 99%.
* Allow remote Pan/Tilt control (Pan : 355°& Tilt : 120°).
* Mechanical IR-Cut device offers outstanding day/night performance, great color.
* (1280 * 720) Pixels 720P/VGA/QVGA, dual stream.
* Allow remote viewing & record from anywhere anytime.
* Wi-Fi compliant with wireless standards IEEE 802.11b/g/n.
* Support TCP/IP, SMTP, HTTP, FTP, PPPOE and other Internet related protocols.

Specifications:

Features:
System Security	Account, password authority management
Free DDNS	Not support free DDNS, supports dynamic IP
View by Phone	Support HD pic IOS, Android mobile view (iOS 4.3, Android OS 2.3 above)
Local Storage	Support up to 32GB MicroSD card, 24-hour loop recording
Monitor Advantage	Support PC computer monitoring, smartphone multi-pic view
PnP	Plug & Play, 99% penetration rate, Easy to setup: 1, connect the network cable and power adapter. 2, install APP, scan UID code to add camera. ?3, Click online camera to view the camera.
QR Code Scanning	UID scan technology applied, easy to operate, and highly confidential.
Upgrade	Upgrade byremote via the web
Reset	Intelligent self repair function
Super Client	1, 4, 9, 16, 25, 36, 64 channel central management software, no user number limitation, centralized surveillance, remote record and playback, alarm email, ect.
System
OS	Embedded Linux OS
Control Protocol	ONVIF 2.0 protocol, high interoperability
Video Coding	Multi stream: 720P(30fps) + VGA(30fps) + QVGA(30fps)
Bit Rate	CBR / VBR, output bit rate range: 128 - 4096kbps
Processor	Hi processor, built in ARM926 Max. 440MHz and high-speed video co-processor
Video
Compression Format	H.264
Frame Rate	30fps/24fps(720p)
Resolution	720P(1280 * 720), VGA(640 * 480), QVGA(320 * 240)
Sensor	1/4 720p Progressive CMOS sensor
Minimum illumination	0.5Lux
SNR	≥54dB
Adjustable Video Parameters	Adjustable Saturation, brightness, contrast and sharpness
IR Control	IR turned on: night vision view enabled, infrared Ray, ICR auto detect. IR turned off: night vision disabled, infrared ray off, ICR stay in day view mode.
Electronic Shutter	1/50s(1/60s)-1/100, 000s
CMOS	Support AWB, AGC, BLC
Lens/Viewing Angle	3.6mm(F1.4)
Night Vision
Night Vision	11pcs 850nmΦ5mm LED, 10m IR distance
Audio
Compression format	ADPCM/32kbps
Audio channel	Built-in MIC, 1 channel audio output
Input	1 Channel Internal -48dB Microphone
Output	1 Internal speaker ( 8Ω1W )
P/T Network
P/T	Pan: 355°, Tilt: 120°
Preset Postion	Support up to 16 preset postions
Network Interface	10Base-T/100Base-TX Ethernet interface
Network Protocol	TCP/IP, UNP/TP, HTTP, UDP, SMTP, FTP, DHCP, DDNS, UPNP, NTP, PPPOE
Wireless Network Security	WPS encryption
Online Visitor	Support 4 online visitors simutaneoursly
IP Address	Dynamic IP and static IP address
WIFI	IEEE 802.11 b/g/n
Alarm
Alarm channel	Alarm input 1 road, 1 road alarm output
Motion Detection	Support motion detecting
System Requirement
System Configuration	Win98 SE/ME/2000/XP, Vista, iOS4.3, The android version 2.3 or higher
Certificate
Certificate	FCC CE RoHS Iphone 4 country code unlock free.
Other Information
Model	TP-C547T
Housing Material	ABS
Application Environment	Indoor
Power Supply	DC 5V 2A
Temperature	-10-55 °C
Power Consumption	Rated power: 3.5W (IR opening ) / maximum power: 7W (P/T working )
Color	White and Black
Item Weight	Approx. 301g / 10.63oz
Item Size	Approx. 11.2 * 13.2 * 13.0cm / 4.41 * 5.20 * 5.12in (L * W * H)
Package Size	Approx. 20.1 * 17.6 * 13.1cm / 7.91 * 6.93 * 5.16in (L * W * H)
Total Weight	Approx. 617g / 21.76oz
Quantity	1pcs
Warranty	1 Year

Network P2p Wifi Ip Cameras User Manuals

Package list:
1 * IP camera
1 * UK Power adapter
1 * Mounting bracket
2 * Mounting screws
1 * CD
1 * User manual
1 * Warranty card
